Nine airports, each on a real day of traffic, from the easiest to the hardest. Tap a card for the airport's briefing, settings and leaderboard; the general instructions follow below.

Radar · approach and departure

You are the approach and departure controller of a real airport on a real day. The job in one breath: bring the arrivals down from their entry points onto the ILS, release the departures and climb them to their exits, and keep everybody 3 NM or 1000 ft apart. Every landing is worth +10, every handoff +5, mistakes cost points. Nothing else is required to start: pick an airport, press start, tap an aircraft.

Reading the scope

The radar scope with arrivals, departures, the final approach and a loss of separation 1 2 3 4 5 6 7 8 9 10 11 12
  1. 1The runways in white and the ILS centreline of the landing runway, dotted, with a tick every mile. The dashed line past the runway is the missed approach.
  2. 2Range rings every 5 NM around the airport, for judging distances at a glance.
  3. 3Entry point (dark blue dot): arrivals appear here and follow the cyan STAR and transition lines towards the final.
  4. 4An arrival on its route, cyan: it follows the published line by itself until you tell it otherwise.
  5. 5An arrival established on the ILS, green: cleared ILS and locked on, it lands by itself.
  6. 6An arrival under vectors: the last line of its tag shows the heading (H230) instead of the next fix.
  7. 7An arrival in a holding (AMIKI-H); the racetrack is dotted on the map.
  8. 8A departure from the main runway, sand-coloured, climbing on its SID (the sand lines) towards its exit; green once cleared to the handoff level.
  9. 9A departure from the second runway, orange, where the airport has one.
  10. 10A loss of separation: both tags and rings turn red until the pair is apart again.
  11. 11The separation ring, 3 NM around every aircraft. On final it becomes an egg when another minimum applies (2.5 NM at Heathrow, wake turbulence in the pro mode): the front reaches as far as the aircraft must stay behind the one ahead, the back as far as its follower needs.
  12. 12Terrain, lakes and coast, decoration only (layer "Terrain & coast"; the dropdown sets the relief strength).

The data block

SWR123/M
A320 EDDF
072↓070 0.7 243
ZH410
  1. 1Callsign and wake category: /L light, /M medium, /H heavy, /J super. Heathrow and Dubai show their own wake-group letters instead.
  2. 2Type and origin (arrivals) or destination (departures). Turboprops show their type in violet: they are slower, plan the gap in front of a jet.
  3. 3Altitude in hundreds of feet with the trend arrow and the cleared altitude (072↓070: passing 7200, descending to 7000; a V while a published altitude of a "descend via STAR" holds it), the vertical speed in thousands of feet per minute, and the speed in the colour of its mode (see "Speed modes").
  4. 4Where it is going: the next fix, H230 for a heading, AMIKI-H for a hold, ILS once established; departures show next fix → exit. Warnings appear here in amber or red: STCA, NO ILS, GO AROUND, IN WX, MRVA 5000, MEDICAL and the other emergencies.

Moving around

  • Drag to pan, pinch or scroll to zoom (or the − / + buttons), double-tap to reset the view.
  • The Layers button opens the panel with the map layers (procedures, holdings, altitude constraints, minimum vectoring altitudes, terrain, separation rings), the voice and the pro modes.
  • Measure turns taps into a measuring line: every tap adds a corner, a tap on an aircraft or a fix snaps to it, and each leg shows its length and bearing. Good for reading track miles to touchdown or the spacing between two aircraft.
  • The top bar shows the clock, pause and time compression (1× to 8×), the runway change button, when the next arrival and departure are due, and the traffic switches (see "Making it easier or harder"). The badge at the bottom right carries the score, the landings and departures so far, the penalty points and the efficiency index; tap it for the violation log.

Controlling an aircraft

Tap an aircraft (or its row in a list) and the command panel opens. Set what you want, read the readback line, press Transmit. Nothing happens before Transmit, and Cancel discards everything.

The command panel with a pending heading, altitude and speed 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
  1. 1Callsign, type, route and origin or destination. While the panel is open the aircraft's remaining route (or its heading) lights up on the scope in its own colour, so you see at once where it is going.
  2. 2What the aircraft is doing now: heading, altitude, speed.
  3. 3Heading ring: drag the handle, or tap −5 / +5. A heading takes the aircraft off its route; the pending value turns amber.
  4. 4Present heading: keep flying straight, whatever the heading at the moment you transmit. The quick way to stop an aircraft at its next turn.
  5. 5Altitude in 1000 ft steps, flight levels above the transition altitude. The quick button under it offers a departure the handoff level and an arrival the altitude of its final approach fix; the five small chips beside it are the next thousands of feet above the panel's floor (3 … 7 for 3000 to 7000 ft).
  6. 6via STAR: descend, but level off at every published altitude of the route until that fix is passed ("descend via"). Without it an arrival descends straight to the cleared altitude. Call for descent asks the pilot to call "request descent" a few miles before the 3° profile to the final approach fix, once; handy for arrivals that appear high and close in.
  7. 7Direct to a fix from the list, or simply tap a fix on the scope while the panel is open. The aircraft flies there and continues along its route. For a departure three passing chips appear: it keeps its SID and turns direct when climbing through that altitude.
  8. 8Speed slider in 10 kt steps, 140 to 300.
  9. 9or less keeps the assigned speed only until the aircraft would fly slower on its own (ticked by default for arrivals, so "180 or less" needs no second call on final); or greater makes it a floor.
  10. 10The speed modes: own speed, 160 to 5 NM, and the quick buttons 140, 180 and 210 kt (next card).
  11. 11Quick speeds 210 kt and 180 kt.
  12. 12Cleared ILS: the aircraft intercepts the localizer and lands by itself when it meets the conditions in "Catching the ILS".
  13. 13Go around for an aircraft on the ILS: the published missed approach, free of charge.
  14. 14Expedite descent (shown when the cleared altitude is well below): 2500 fpm, the speed creeps up while it lasts.
  15. 15Hold at the next holding fix of the route; press again to continue. Every entry point has a holding.
  16. 16The readback says in plain words what you are about to transmit. With "Speak transmissions" on, the pilot reads it back aloud.
  17. 17Cancel and Transmit.

Two more panel buttons appear when needed: Handoff is automatic, and Approve deviation answers a pilot who asks for a turn around a thunderstorm, and the same button later approves the direct the pilot asks for once clear of the weather.

Speed modes the colour of the speed in the tag

  • Own speed (the default): the aircraft keeps its speed and slows by itself on final: 210 kt by 12 NM, 200 by 10, 180 by 8, 160 by 6, approach speed from 4 NM. Nothing to do for you.
  • 160 → 5: 160 kt until 5 NM (4 NM at Heathrow), then approach speed. The classic spacing call on final.
  • Assigned: exactly the speed you set, all the way to the runway if you never change it. Turns red when it is faster than own speed would allow at that distance.
  • Below FL100 everybody is capped at 250 kt. Departures fly their own climb profile until you assign a speed.
  • Turboprops (Dash 8, PC-12, TBM, King Air) are slower, 200 to 240 kt on arrival and 95 to 125 kt on final; the slider stops at their maximum and the panel shows their schedule.

Catching the ILS

An arrival captures the ILS when all of this is true at the final approach fix of the runway (its altitude is on the map and in the airport's briefing):

  • it has been cleared ILS (the tag turns green; yellow-green while its cleared altitude is still too high for the capture, fix that),
  • it is at the fix altitude, or within the airport's tolerance above it (300 to 500 ft; some airports accept a capture from higher up, see their briefing),
  • it meets the localizer at 45° or less, inside 40 NM of the runway, as far as the dotted centreline is drawn; a small red bar on the centreline marks the point nearest the runway where a join is still possible, and the layer "ILS intercept guides" draws 45° lines at every fix on the final where the localizer can be joined,
  • and it is not faster than 160 kt when it reaches the runway.
  • Otherwise the tag shows NO ILS or UNSTABLE, the aircraft flies the missed approach and it costs 15 points.
  • The published transitions bring an arrival onto the final already lined up: get it down to the fix altitude and cleared ILS before the fix, and the rest happens on its own. The approach clearance never changes the altitude: the aircraft keeps what you cleared until the glide path comes down to it, with or without via STAR.
  • Fixes on the extended centreline wear a faint white ring: hover over one, or tap it with nothing selected, and a label shows its published altitude and the glide-path altitude at that point, the highest an aircraft level there can still catch.
  • A direct-to to a fix on the final (the ones on the centreline, such as the final approach fix) joins the localizer there; a vector may join the final down to the airport's minimum join distance.
  • Your own Go around is free. About 3 % of approaches go around by themselves (amber GO AROUND), also free; a go-around climbs on the missed approach to its holding and is not counted against departures until it has reached its initial altitude.

The lists: arrivals, departures and notices

The arrival sequence strip, the take-off queue and a new-arrival notice 1 2 3 4 5 6 7 8 9 10 11
  1. 1New arrival: callsign, type, entry point, altitude and stand. The notice flashes, then stands until you have given that aircraft its first instruction; tapping it opens the panel. Only three stand at a time, older ones fold into a "+4 earlier" line.
  2. 2The arrival sequence: every inbound aircraft in landing order, with the count; one sub-list per runway where the airport lands on several. Green once established on the ILS. Tap a row to open its panel.
  3. 3Miles to go to the threshold along its route.
  4. 4Estimated time to go until the landing, in minutes and seconds (the picture still shows it as a clock time).
  5. 5The gap in track miles behind the aircraft ahead on the same runway.
  6. 6How much more than the minimum that gap is: green, amber within a mile of the minimum, red below it. The minimum is the one this pair needs on final (3 NM, 2.5 NM at Heathrow, the wake minimum in the pro mode).
  7. 7The take-off queue with a timer per runway since its last take-off: green when the first aircraft may go, red while a rule still blocks it, with the reason under its row.
  8. 8The next arrival's miles to go to the threshold, amber inside 3 NM: your cue for a departure that shares the runway.
  9. 9T/O releases the first aircraft of a runway. Main runway sand, second runway copper.
  10. 10Each row: callsign, type and wake group, destination, stand, runway, SID and the waiting time since it became ready (amber from 15 min, red from 30).
  11. 11The − folds a list to its header line; the folded queue keeps the first aircraft per runway and its button.

Releasing departures

  • Press T/O when the timer is green. You may release against a red rule, but every rule you break costs 10 points.
  • Amber is a caution, not a rule: the last departure from the parallel runway flies a route that does not diverge from this one and is still within 4 NM. You may release without a penalty, but the two climb out side by side, so separate them yourself with an altitude or a few miles of spacing.
  • Wake turbulence: 2 min behind a heavy, 3 min behind an A380, 2 min for a light behind a medium, nothing between two mediums. Heathrow and Dubai use their own wake-group intervals, shown in the queue.
  • Runway: the previous departure must be airborne. On a runway shared with arrivals, a departure still rolling when an arrival crosses the threshold costs 20.
  • Crossing runways: the last departure from the other runway must be past the intersection.
  • Arrival on final: where a departure runway crosses or shares the final, no release with an arrival inside the airport's distance (see its briefing).
  • Dependent parallel departures: when the SID does not diverge from the SID of the last departure on the parallel runway, that aircraft must be 4 NM away first.
  • Departures climb by themselves to the airport's initial altitude. Clear them to the handoff level (the quick button in the panel): the tag turns green and they are handed off automatically at their exit, within 5 NM of it, or outbound past it on a heading. Until then they fly on and stay in your separation.

Separation, alerts and penalties

  • The minimum is 3 NM or 1000 ft, everywhere. Two aircraft established on the same ILS are separated by distance alone, all along the final (the one behind is always higher); at Heathrow that in-trail minimum is 2.5 NM inside 10 NM of the runway.
  • An aircraft within 100 ft of its cleared altitude counts as level there: a level-off settling 60 ft high is no conflict, 900 ft against a level aircraft is.
  • The separation ring draws the minimum around every aircraft: nobody within 1000 ft of its level belongs inside it. On final, with the pro mode wake separation on final, the ring becomes an egg. Its front reaches as far as the aircraft must stay behind the one ahead, its back as far as the follower must stay behind. The follower is the next aircraft in the arrivals list, also while it is still on its way to the final; with nobody behind, a Medium is assumed.
Two A320s on final, 3.4 NM apart, each with a circular 3 NM ring
A320 behind A320 · 3 NM. Two Mediums have no wake minimum, so both rings stay circles. The follower is 3.4 NM behind, just outside the leader's ring.
An A320 5.4 NM behind a Boeing 777 on final, both rings stretched into eggs
A320 behind a B777 · 5 NM. The Heavy's egg reaches 5 NM back, the A320's 5 NM forward. At 5.4 NM the follower sits just behind the tip.
A Boeing 777 6.4 NM behind an Airbus A380 on final, with long eggs
B777 behind an A380 · 6 NM. The A380's egg reaches 6 NM back. The 777's own tail is drawn for a Medium follower, 5 NM, as long as nobody follows it in the arrivals list.

The pairs above use the ICAO categories; Heathrow and Dubai have their own tables (see their briefings). The arrivals board gives the same in numbers: the gap behind the aircraft ahead and the margin over the minimum.

Two converging aircraft with amber tags reading STCA and a dashed line between them

Short-term conflict alert. The warning before it costs anything.

  • Both tags turn amber with STCA and a blinking dashed line joins the pair.
  • A blinking amber notice with both callsigns appears above the lists, so you see it while zoomed in elsewhere. A tap centres the scope on the pair and silences the notice; the tags stay amber until the pair is resolved.
  • It fires when two aircraft would come closer than the minimum within 90 s at their present speeds and rates.
  • An aircraft on its route is predicted along that route, turns included. One on a heading is predicted straight ahead.
  • Two aircraft on their routes also alert when they will pass within half a mile of the minimum.
  • In the picture: DLH4KM is descending through 6900 ft to 5000, SWR59EB is level at 6000. Their tracks meet in about a minute, with less than 1000 ft between them.
  • The way out: stop the descent at 7000 ft, or turn one behind the other. The alert cannot know a turn you have not given yet, so it clears as soon as yours takes effect.
  • It costs nothing. Treat it as the moment to act.
  • A loss of separation turns both aircraft red: 20 points, and 10, 20, 30 … more for every 30 s it lasts.
  • Not counted against you: departures on their initial climb, departures against ILS traffic until their SID has turned them away (the procedure's independent part), parallel-runway operations (a climbing departure against an arrival on the other runway's ILS, two departures on diverging SIDs), the straight part of a missed approach against ILS traffic, and a go-around against departures until it has reached its initial altitude.
EventPoints
Landing · handoff+10 · +5
Loss of separation−20, then −10, −20, −30 … every 30 s unresolved
Missed approach (ILS not caught) · unstable, faster than 160 kt at the runway−15
Aircraft leaves the area−20
Release against a rule (wake, runway occupied, crossing, arrival on final, dependent SID)−10 each
Departure still on a shared runway as an arrival crosses the threshold−20
Thunderstorm cell entered (pro mode)−10, then −5 every 30 s inside
Below the minimum vectoring altitude under vectors (pro mode)−10, then −5 every 30 s
Pilot's weather request unanswered for 30 s−5

Tap the score badge for the violation log: every penalty with time, reason and a snapshot of the scope at that moment. Every landing, handoff and penalty is weighted with the difficulty in force at that moment (traffic share and pro modes); the average difficulty of the session is shown next to the score.

Emergencies and pilot requests

With the pro mode non-standard events on (rare: about one per two hours, med: one per hour, high: one per 20 minutes, never two at once), pilots call with a problem. A notice stays in the corner until you tap it, the tag carries a symbol and a label, and the pilot's call is spoken when the voice is on.

  • Medical emergency (red cross): sequence it first. +45 for a landing within the direct-routing time, −10 for a hold or for still being airborne after it.
  • Minimum fuel (fuel drop): the same, and after 8 minutes it declares MAYDAY fuel, when a hold or a go-around costs 30.
  • Radio failure (crossed circle, 7600): the aircraft takes no instructions and flies the published route to the ILS, or its SID to the exit. Keep everybody else out of its way: +45 when it gets there without a loss of separation around it.
  • Emergency descent (red arrow, from above FL100): 4000 fpm down to FL100 or the minimum vectoring altitude, whatever you clear; losses of separation in its first minute are logged but not scored. Once level it asks for priority, +60 for the landing.
  • Engine failure after take-off (U-turn, any departure below 12,000 ft): it stops its climb and asks for vectors back to the ILS; it is an arrival from then on, +60 for the landing. On one engine it climbs at only 40 % of the normal rate, so plan any climb and a possible go-around accordingly.
  • Weather deviation (lightning, whenever thunderstorms are on): an aircraft about 45 s from a cell asks for a heading that takes it clear of the storm, as long as you assign it within 15 s. A pilot who needs a large turn asks earlier. Approve it in the panel or give a heading or a direct-to of your own. If you wait longer the pilot may ask for a larger turn; unanswered after 30 s the aircraft turns by itself and you lose 5. Once an aircraft is deviating, whether you approved its request, gave it a heading of your own or it turned by itself, it reports "clear of weather, request direct <next fix>" after two minutes without an instruction, as soon as its heading and the way back to its route are clear; the panel button approves the direct, any other instruction answers the call.
  • The direct-routing time is what the aircraft would need straight to the runway from where it was when it called, plus three minutes, at least ten minutes in all. Vectors cost nothing as long as it lands within that.
  • Once the aircraft has landed or been handed off, a notice reports the outcome: green "Emergency well handled" with the points, or red with the cause. An aircraft with an emergency never makes the random go-around.
  • The symbol buttons under the mode in the Layers panel trigger an event by hand on a random suitable aircraft, in any mode; the dice picks one at random.

Making it easier or harder

  • ARR 100% in the top bar thins the arrivals to 80, 60, 40 % or off; DEP on switches departures off. Arrivals only or departures only are both good ways to learn.
  • Time compression 1× to 8×, and pause. Tap the clock to start at another time of day; the airport's briefing shows the traffic over the day.
  • Timetable and skipping ahead: the top bar shows when the next arrival and departure are due; tap it for the next ten of each. When the scope and the queue are empty and nothing is due for two minutes, a Skip to … button jumps the clock ahead.
  • Resume: the game saves itself on your device every 30 s. A reload of the radar page continues where it was, paused; after a break the airport's start card offers Resume. Starting a new game or saving the score discards it.
  • Save for later: tap the clock, then Save for later (code). You get a six-character code that brings the session back on any device: enter it under Have a save code? on the airport's start card. Valid for 30 days after the last save.
  • Scores of a continued session: after saving a score you can go back to the scope and play on. An entry from a session that was taken up again (Resume, a save code or a reload) carries a faint amber S on the boards.
  • Runway change: the RWY button in the top bar switches to another runway concept of the airport, at your timing: it is blocked while an arrival is on the ILS or a departure on the runway, so make the gap first. Arrivals get the new runway's routes, every ILS clearance is withdrawn, departures finish their SID, and your score carries over.
  • Pro mode, wake turbulence on final: between aircraft on the ILS the wake minima replace the 3 NM (4 NM heavy behind heavy, 5 NM medium behind heavy, 6 NM light behind heavy, 5 NM light behind medium, 6 to 8 NM behind an A380; Heathrow and Dubai use their own six- and seven-group schemes, see their briefings). The ring becomes the egg described above. +25 % difficulty.
  • Pro mode, second departure runway versus the final: second-runway departures are separated from ILS traffic like any other aircraft as soon as their initial climb is over, and the release rule against arrivals on final applies. +25 %.
  • Pro mode, thunderstorms: one to three storm systems, about 10 NM across, drift through the area at 20 kt, drawn like a weather radar in green, yellow and red. They keep clear of the airport, the final approach and the exits, nothing else: route around them, use the holdings, hand departures off abeam their exit. An aircraft in the yellow or red part costs 10 points and 5 more for every further 30 s (IN WX); the first minute after an aircraft appears is free. +25 % per storm.
  • Pro mode, minimum vectoring altitudes: the sectors of the published chart (layer "Minimum vectoring altitudes", also available without the mode) are enforced the way they are in reality: an aircraft on a heading or a direct-to that is actually below the minimum of its sector costs 10 points and 5 more per 30 s (MRVA 5000). A clearance below the sector while the aircraft is still above it only shows a note: that is normal practice when it will reach a lower sector first. Published routes, holdings, the ILS and the missed approach are not checked. +25 %.
  • Pro mode, non-standard events: see "Emergencies and pilot requests". +12.5 % on rare, +25 % on med, +50 % on high.

Efficiency. Next to the score, in teal, an index from 0 to 100 that is never part of the score: how tightly you used the runway on final, the track miles you saved arrivals and departures against their published routes, and how promptly you released departures once they could go. Tap the score badge for its four parts; the index is stored with your session for your own comparison.

Tips from the tower

  • Arrivals on the published transitions join the localizer already lined up. Get them to the fix altitude and cleared ILS early, and the rest happens on its own.
  • Own speed does the slowing down for you on final. Assign speeds only to build or protect a gap, and switch back to own speed afterwards.
  • Watch the arrival sequence strip: a red or amber margin there is the gap you have to make before the final, with speed, a longer downwind or a direct-to.
  • A go-around climbs to its initial altitude towards its holding and accelerates to 210 kt. Give it a new heading or direct-to early, before it reaches the hold.
  • Spacing departures one minute apart generally gives enough separation later on the way out.
  • A departure that shares the runway with arrivals needs the biggest gap. Look at the "arr" miles to go in the queue before you plan the next arrival onto short final.
  • On an iPad, add this page to the home screen for a full-screen app. Your settings are remembered.

Tower & ground Zurich only

The airport layout follows the real aerodrome: runways, taxiways, aprons, buildings and all 153 stands at their actual positions. You work tower and ground at once, in the same three runway concepts as the radar. Arrivals appear on an 8 NM final and need a landing clearance by 1 NM; after touchdown they roll out to the exit you assigned (or the concept's default), stop clear of the runway and wait for a taxi clearance to their planned stand. Departures appear at their stand at off-block time and need push-back (or, from the self-manoeuvring stands, just a taxi clearance), a taxi route to a holding point of their runway, clearance for every runway crossing on the way, and the take-off clearance.

Giving clearances

  • Tap an aircraft on the map, in the final list or in the waiting list to open its command bar. Everything is applied at once (and read back by voice if it is on).
  • Arrivals: Land and GA are right in the final list; the command bar lets you choose the exit. The taxi clearance to the stand can be given early, on final or during the roll-out, and is applied once the aircraft has vacated.
  • Departures: push-back, taxi, hold position, continue, Cross RWY at every runway on the route, then line up and take off or line up and wait followed by cleared for take-off. The holding point and, for arrivals, another free stand of the same sector can be chosen from a dropdown.
  • Taxi routes: without instructions the aircraft takes the shortest taxiway route. To dictate it, tap taxiway designators on the map or press the taxiway buttons under the route line in succession; the route then follows those taxiways in that order. The dashed preview and the readback show what you are about to clear.
  • Turn back resolves a nose-to-nose standstill by sending one aircraft back to the previous junction and around.

Rules

  • No runway crossing while an arrival is inside 4 NM on approach, until it has passed the crossing point; a crossing with a departure rolling is as bad. A route stops 75 m short of every runway it crosses until you clear the crossing.
  • Take-off clearances follow the radar's release rules: wake turbulence interval, runway occupied, crossing runway, arrival inside the concept's distance. Lining up and waiting is free; the rules bite with the take-off clearance.
  • A blocked runway inside 1 NM, or no landing clearance by 1 NM, means a go-around.
  • Taxi speeds: 20 kt straight, 10 kt in turns, 8 kt near the stands; aircraft keep 45 m behind the one ahead and queue at the holding point by themselves.
  • The side panel shows the aircraft on final, everybody waiting for push-back, taxi or take-off with their waiting time (amber from 3 min, red from 8), the score and the log.

Scoring

EventPoints
Arrival at its stand · departure airborne+10, minus 1 per minute the aircraft had to wait (minimum +2)
Go-around, no landing clearance−15
Go-around, runway blocked−20
Runway crossing with an arrival inside 4 NM or a departure rolling−20
Take-off against a release rule−10 each
Push-back into the path of a taxiing aircraft−15
Two aircraft nose to nose without an exit−40

Finish session & save score in the left panel enters your result on the ground board, separate from the radar's and without difficulty weighting.
